Description
FortiWiFi 80F Series x Versatile Converged NGFW & SD-WAN with WiFi-6 and Multiple Connectivity Options
The FortiWiFi 80F series is a feature-rich desktop security appliance delivering strong NGFW and SD-WAN performance with dual SFP/RJ45 shared media WAN ports and an extensive range of variants x including PoE, DSL, 3G4G, and WiFi-6 x making it one of the most flexible branch office platforms in the Fortinet lineup.
Key Performance
1.4 Gbps IPS Throughput
1 Gbps NGFW Throughput
900 Mbps Threat Protection Throughput
10 Gbps Firewall Throughput
6.5 Gbps IPsec VPN Throughput
1.5 Million Concurrent Sessions
715 Mbps SSL Inspection Throughput
5,000 Firewall Policies
Interfaces & Hardware (Base Model)
2x GE RJ45/SFP Shared Media WAN Ports
6x GE RJ45 Internal Ports
2x GE RJ45 FortiLink Ports (for FortiSwitch integration)
Trusted Platform Module (TPM) for hardware cryptographic security
Bluetooth Low Energy (BLE) support
Desktop, wall-mount, or rack tray form factor
Supports dual redundant power adapters
Available Variants
80F / 81F x Standard model; 81F adds 128GB SSD onboard storage
80F-Bypass x Includes a LAN bypass port pair for inline deployment scenarios
80F-POE / 81F-POE x Replaces internal ports with 6x PoE+ ports + 2x PoE+ FortiLink ports, 96W total PoE budget
FWF-80F-2R / 81F-2R x Adds dual WiFi-6 radio (802.11ax) with dedicated scanning radio
FWF-81F-2R-POE x WiFi-6 dual radio + PoE+ + 128GB SSD
80F-DSL x Adds embedded xDSL modem (VDSL2/ADSL2+)
FWF-80F-2R-3G4G-DSL x WiFi + embedded 3G4G/LTE modem + DSL, 2x SIM slots
FWF-81F-2R-3G4G-DSL x As above with 128GB SSD
FWF-81F-2R-3G4G-POE x WiFi + 3G4G/LTE + PoE+ + 128GB SSD
Security Features
FortiGuard AI-Powered Security Services with 18,000+ IPS signatures
Real-time SSL/TLS 1.3 deep packet inspection x 715 Mbps SSL inspection throughput
Anti-malware combining antivirus and cloud sandboxing
DNS and URL filtering across 300+ million URLs
AI-powered inline malware prevention for sub-second zero-day blocking
OT security with 1,000+ virtual patches and 3,300+ protocol rules
Data Loss Prevention (DLP) and inline CASB
Universal ZTNA x agent-based via FortiClient or agentless via proxy portal
Networking & SD-WAN
Full SD-WAN built-in at no extra cost via FortiOS
Patented SP4 SD-WAN ASIC for fastest application identification and IPsec acceleration
Supports up to 24 FortiSwitches and 96 FortiAPs for SD-Branch deployments
Active-Active, Active-Passive, and Clustering HA configurations
Management
Managed via FortiManager (enterprise) or FortiGate Cloud (SMB)
Zero-touch provisioning for rapid branch deployment
GenAI-assisted configuration and troubleshooting via FortiAI
View data sheet: FortiGate FortiWiFi 80F Series Data Sheet
