Description
FortiWiFi 80F Series x Versatile Converged NGFW & SD-WAN with WiFi-6 and Multiple Connectivity Options
The FortiWiFi 80F series is a feature-rich desktop security appliance delivering strong NGFW and SD-WAN performance with dual SFP/RJ45 shared media WAN ports and an extensive range of variants x including PoE, DSL, 3G4G, and WiFi-6 x making it one of the most flexible branch office platforms in the Fortinet lineup.
Key Performance
- 1.4 Gbps IPS Throughput
- 1 Gbps NGFW Throughput
- 900 Mbps Threat Protection Throughput
- 10 Gbps Firewall Throughput
- 6.5 Gbps IPsec VPN Throughput
- 1.5 Million Concurrent Sessions
- 715 Mbps SSL Inspection Throughput
- 5,000 Firewall Policies
Interfaces & Hardware (Base Model)
- 2x GE RJ45/SFP Shared Media WAN Ports
- 6x GE RJ45 Internal Ports
- 2x GE RJ45 FortiLink Ports (for FortiSwitch integration)
- Trusted Platform Module (TPM) for hardware cryptographic security
- Bluetooth Low Energy (BLE) support
- Desktop, wall-mount, or rack tray form factor
- Supports dual redundant power adapters
Available Variants
- 80F / 81F x Standard model; 81F adds 128GB SSD onboard storage
- 80F-Bypass x Includes a LAN bypass port pair for inline deployment scenarios
- 80F-POE / 81F-POE x Replaces internal ports with 6x PoE+ ports + 2x PoE+ FortiLink ports, 96W total PoE budget
- FWF-80F-2R / 81F-2R x Adds dual WiFi-6 radio (802.11ax) with dedicated scanning radio
- FWF-81F-2R-POE x WiFi-6 dual radio + PoE+ + 128GB SSD
- 80F-DSL x Adds embedded xDSL modem (VDSL2/ADSL2+)
- FWF-80F-2R-3G4G-DSL x WiFi + embedded 3G4G/LTE modem + DSL, 2x SIM slots
- FWF-81F-2R-3G4G-DSL x As above with 128GB SSD
- FWF-81F-2R-3G4G-POE x WiFi + 3G4G/LTE + PoE+ + 128GB SSD
Security Features
- FortiGuard AI-Powered Security Services with 18,000+ IPS signatures
- Real-time SSL/TLS 1.3 deep packet inspection x 715 Mbps SSL inspection throughput
- Anti-malware combining antivirus and cloud sandboxing
- DNS and URL filtering across 300+ million URLs
- AI-powered inline malware prevention for sub-second zero-day blocking
- OT security with 1,000+ virtual patches and 3,300+ protocol rules
- Data Loss Prevention (DLP) and inline CASB
- Universal ZTNA x agent-based via FortiClient or agentless via proxy portal
Networking & SD-WAN
- Full SD-WAN built-in at no extra cost via FortiOS
- Patented SP4 SD-WAN ASIC for fastest application identification and IPsec acceleration
- Supports up to 24 FortiSwitches and 96 FortiAPs for SD-Branch deployments
- Active-Active, Active-Passive, and Clustering HA configurations
Management
- Managed via FortiManager (enterprise) or FortiGate Cloud (SMB)
- Zero-touch provisioning for rapid branch deployment
- GenAI-assisted configuration and troubleshooting via FortiAI
View data sheet: FortiGate FortiWiFi 80F Series Data Sheet
