FortiWiFi 70G Series — High-Performance Converged NGFW, SD-WAN & WiFi-6
The FortiWiFi 70G series is a compact desktop security appliance that steps up performance significantly for larger branch offices and distributed enterprise sites, delivering 10 Gbps firewall throughput with dual WAN ports, built-in WiFi-6, and optional PoE — all in a fanless desktop form factor powered by Fortinet's patented SP5 ASIC.
Key Performance
- 2.5 Gbps IPS Throughput
- 1.5 Gbps NGFW Throughput
- 1.3 Gbps Threat Protection Throughput
- 10 Gbps Firewall Throughput
- 7.1 Gbps IPsec VPN Throughput
- 1.4 M Concurrent Sessions
- 1.4 Gbps SSL Inspection Throughput
- 5,000 Firewall Policies
Interfaces & Hardware (Base Model)
- 2x GE RJ45 WAN Ports
- 6x GE RJ45 Internal Ports
- 2x GE RJ45 FortiLink Ports (for FortiSwitch integration)
- Built-in dual-radio 802.11a/b/g/n/ac/ax WiFi-6 (2.4GHz/5GHz) — FortiWiFi models
- Trusted Platform Module (TPM) for hardware cryptographic security
- Signed Firmware Hardware Switch for physical firmware validation
- Bluetooth Low Energy (BLE) support
- Fanless desktop form factor, wall-mountable
Available Variants
- 70G / FWF-70G — Standard model with WiFi-6
- 71G / FWF-71G — Adds 64GB SSD onboard storage
- 70G-POE / FWF-70G-POE — Replaces 4x internal ports with 4x PoE+ ports (60W total budget), suited for powering FortiAPs or IP phones directly
- 71G-POE — PoE+ with 64GB SSD storage
Security Features
- FortiGuard AI-Powered Security Services with 18,000+ IPS signatures
- Real-time SSL/TLS 1.3 deep packet inspection — 1.4 Gbps SSL inspection throughput
- Anti-malware combining antivirus and cloud sandboxing
- DNS and URL filtering across 300+ million URLs
- AI-powered inline malware prevention for sub-second zero-day blocking
- OT security with 1,000+ virtual patches and 3,300+ protocol rules
- Data Loss Prevention (DLP) and inline CASB
- Universal ZTNA — agent-based via FortiClient or agentless via proxy portal
Networking & SD-WAN
- Full SD-WAN built-in at no extra cost via FortiOS
- Patented SP5 SD-WAN ASIC for fastest application identification and IPsec acceleration
- Supports up to 24 FortiSwitches and 96 FortiAPs — significantly larger SD-Branch deployments than the 30G/50G series
- Active-Active, Active-Passive, and Clustering HA configurations
Management
- Managed via FortiManager (enterprise) or FortiGate Cloud (SMB)
- Zero-touch provisioning for rapid branch deployment
- GenAI-assisted configuration and troubleshooting via FortiAI
View datasheet: FortiGate FortiWiFi 70G Series Data Sheet
