Fortinet FortiGate 81F-POE (FG-81F-POE)
Branch NGFW + SD-WAN with Integrated PoE and Onboard Storage
The FortiGate 81F-POE is a high-performance next-generation firewall designed for distributed enterprise branches that require integrated PoE switching, advanced security, and SD-WAN in a single compact appliance. Powered by FortiOS and Fortinets patented Secure SD-WAN ASIC (SP4), the 81F-POE delivers enterprise-grade protection with optimized application performance and lower power consumption compared to CPU-only firewalls.
As part of the Fortinet Security Fabric, the FG-81F-POE works seamlessly with FortiGuard AI-Powered Security Services to provide real-time, automated protection against modern and zero-day threats.
Performance (Enterprise Traffic Mix)
-
IPS: 1.4 Gbps
-
NGFW: 1 Gbps
-
Threat Protection: 900 Mbps
-
SSL Inspection (IPS avg HTTPS): 715 Mbps
-
Firewall Throughput: 10 / 10 / 7 Gbps
-
IPsec VPN: 6.5 Gbps
-
SSL-VPN: 950 Mbps
-
Concurrent Sessions: 1.5 Million
-
New Sessions/sec: 45,000
Key Hardware Features
PoE Switching Built-In
-
6 x GE RJ45 PoE/+ ports
-
2 x GE RJ45 PoE/+ FortiLink ports
-
Total PoE Budget: 96W
-
Up to 30W per port (802.3at)
Perfect for powering:
-
FortiAP wireless access points
-
VoIP phones
-
Security cameras
-
IoT branch devices
Dual WAN Flexibility
-
2 x GE RJ45/SFP shared media WAN ports
-
Supports fiber or copper handoff without media converters
Onboard Storage
-
128GB SSD included
-
Ideal for local logging, analytics, and enhanced reporting
Hardware Security
-
Trusted Platform Module (TPM) for hardware-level key protection
-
Bluetooth Low Energy (BLE) for simplified onboarding
Use Cases
Secure Branch
-
Integrated firewall + PoE switching
-
Extends security to LAN and WLAN via FortiLink
-
Supports up to 24 FortiSwitches and 96 FortiAPs (48 tunnel mode)
Secure SD-WAN
-
Built-in SD-WAN with application steering
-
WAN optimization and overlay acceleration
-
Ideal for multi-ISP branch resilience
Perimeter Protection
-
Deep SSL inspection (TLS 1.3)
-
AI-driven IPS and anti-malware
-
URL/DNS filtering and botnet protection
Universal ZTNA
-
Enforce policy-based access to internal apps
-
Agent-based (FortiClient) or proxy access
Physical Specifications
-
Form Factor: Desktop / Wall Mount / Rack Tray
-
Dimensions: 2.4 x 8.5 x 7.0 in (60 x 216 x 178 mm)
-
Weight: 3.1 lbs (1.4 kg)
-
Noise Level: 31.56 dBA (PoE model uses active cooling)
-
Power Consumption: 98W average / 137W max
-
Operating Temp: 0Å“40°C
Why Choose the 81F-POE?
Choose the FG-81F-POE if your branch requires:
-
Integrated PoE switching (96W)
-
Onboard 128GB storage
-
Fiber WAN flexibility (SFP support)
-
High-performance NGFW + SD-WAN
-
Centralized management via FortiManager or FortiGate Cloud
It removes the need for a separate PoE switch in small branch environments while maintaining full enterprise-grade security.
View data sheet: FortiGate FortiWiFi 80F Series Data Sheet
