Fortinet FortiGate 81F
Branch-ready NGFW + SD-WAN with onboard storage
The Fortinet FortiGate 81F is a high-performance next-generation firewall designed for distributed enterprise branches and mid-sized offices that need strong security, integrated SD-WAN, and local storage for logging and analytics. Built on Fortinets patented Secure SD-WAN ASIC (SP4) and powered by FortiOS, the 81F converges networking and security into a single, centrally managed appliance.
As part of the Fortinet Security Fabric, the 81F works seamlessly with FortiGuard AI-Powered Security Services to deliver real-time, coordinated protection across users, devices, and applications.
Key Performance (Enterprise Traffic Mix)
-
IPS: 1.4 Gbps
-
NGFW: 1.0 Gbps
-
Threat Protection: 900 Mbps
-
SSL Inspection (IPS avg HTTPS): 715 Mbps
-
IPsec VPN: 6.5 Gbps
-
SSL-VPN Throughput: 950 Mbps
-
Concurrent Sessions: 1.5 million
-
New Sessions/sec: 45,000
Hardware Overview
Interfaces
-
2 x GE RJ45/SFP shared media WAN ports
-
6 x GE RJ45 internal ports
-
2 x GE RJ45 FortiLink ports (default)
-
1 x USB 3.0
-
1 x Console (RJ45)
Storage
-
128GB onboard SSD (key difference vs FG-80F)
Security Hardware
-
Trusted Platform Module (TPM)
-
Bluetooth Low Energy (BLE)
Form Factor
-
Desktop / wall mount / rack tray
-
Fanless (0 dBA)
-
Compact branch-friendly design
Why Choose the 81F Over the 80F?
The primary difference between the 80F and 81F is the integrated 128GB SSD on the 81F. This makes the 81F ideal when:
-
Local logging is required
-
You plan to store analytics or reports locally
-
You want added flexibility for advanced services
If you do not need onboard storage, the 80F provides the same security performance without SSD.
Use Cases
Perimeter Protection
-
Deep SSL inspection (including TLS 1.3)
-
Intrusion prevention (IPS)
-
Malware and application control
-
AI-driven zero-day threat prevention
Secure SD-WAN
-
Application-aware traffic steering
-
WAN optimization
-
Integrated SASE capabilities
-
Centralized management via FortiManager or FortiGate Cloud
Secure Branch
-
Integrated FortiSwitch and FortiAP support
-
IoT device visibility and segmentation
-
High Availability (Active-Active / Active-Passive / Clustering)
Universal ZTNA
-
Agent-based (FortiClient) or agentless access
-
Continuous authentication and posture checks
View data sheet: FortiGate FortiWiFi 80F Series Data Sheet
