Description
Fortinet FortiGate 80F-DSL
Branch NGFW + SD-WAN with Integrated xDSL Connectivity
The Fortinet FortiGate 80F-DSL is a next-generation firewall designed for branch and distributed enterprise sites that require built-in DSL connectivity without relying on external modems. It combines enterprise-grade security, integrated SD-WAN, and xDSL WAN support in a single compact appliance running on FortiOS.
Powered by Fortinets purpose-built Secure SD-WAN ASIC (SP4), the 80F-DSL delivers high security performance with lower latency and reduced power consumption compared to CPU-based firewalls.
Performance (Enterprise Traffic Mix)
-
IPS: up to 1.4 Gbps
-
NGFW: up to 1.0 Gbps
-
Threat Protection: up to 900 Mbps
-
SSL Inspection (IPS avg HTTPS): up to 715 Mbps
-
IPsec VPN: up to 6.5 Gbps
-
SSL-VPN throughput: up to 950 Mbps
-
Concurrent sessions: 1.5 million
-
New sessions/sec: 45,000
Built-In DSL (No External Modem Required)
The 80F-DSL includes an embedded xDSL modem (RJ11) supporting:
-
VDSL2
-
ADSL2 / ADSL2+
-
G.DMT
-
T1.413
-
G.Lite
-
Annex A, B, I, J, M & L
Ideal for:
-
Regional or rural sites
-
Retail stores with legacy DSL circuits
-
Backup WAN over DSL
-
Temporary branch or construction environments
Interfaces
-
2 x GE RJ45/SFP shared media WAN ports
-
1 x DSL RJ11 port (embedded modem)
-
6 x GE RJ45 internal ports
-
2 x GE RJ45 FortiLink ports
-
1 x USB 3.0
-
1 x Console (RJ45)
Security & Fabric Integration
The FortiGate 80F-DSL integrates seamlessly with:
-
FortiGuard AI-Powered Security Services
-
Fortinet Security Fabric
-
FortiSwitch & FortiAP (via FortiLink)
-
FortiManager (centralized management)
-
FortiGate Cloud (SMB SaaS management)
Included Platform Capabilities
-
Integrated SD-WAN (no extra license)
-
Universal ZTNA enforcement
-
Deep SSL/TLS 1.3 inspection
-
Application Control
-
IPS & Anti-Malware
-
IoT device detection
-
OT security inspection
-
High Availability support (Active-Active / Active-Passive)
Form Factor & Power
-
Desktop / Wall mount
-
Fan: ~24 dBA
-
Dimensions: 60 x 216 x 178 mm
-
Power: 12V DC (dual redundancy optional)
-
Power consumption: ~28W average
Ideal Use Cases
Retail branches using DSL circuits
Remote offices without fiber availability
Backup WAN deployments
Distributed enterprise with centralized management
Secure SD-WAN edge with embedded DSL
View data sheet: FortiGate FortiWiFi 80F Series Data Sheet
