Description
Fortinet FortiGate 700G Series (FG-700G / FG-701G)
High-performance enterprise NGFW + Secure SD-WAN + Segmentation with 25G uplinks (NP7 + CP10)
The FortiGate 700G Series is a 1RU enterprise firewall built for campus core/edge, data-center segmentation, and high-throughput WAN edge deployments where you need serious inspection throughput (including SSL) and 25GbE interface optionswithout turning security into a bottleneck.
At-a-glance performance (Enterprise Traffic Mix)
-
IPS: 38 Gbps
-
NGFW: 29 Gbps
-
Threat Protection: 26 Gbps
-
SSL Inspection (IPS avg HTTPS): 14 Gbps
-
IPsec VPN (512B): 55 Gbps
-
SSL-VPN: 8 Gbps
-
Concurrent Sessions: 16 million
-
New Sessions/sec: 700,000
-
Firewall Throughput (IPv4/IPv6): 164 / 163 / 145 Gbps
-
Firewall Policies: 10,000
-
VDOMs: 10 default / up to 50
-
Max FortiAPs: 1024 total / 512 tunnel
-
Max FortiSwitches: 96
Translation for customers: this is for environments where you want full-featured inspection at tens of gigabits, and still keep headroom for growth.
Interfaces (designed for enterprise switching + fast uplinks)
From the spec and front-panel layout:
-
4 x 25GE SFP28 (25G/10G capable)
-
4 x 10GE SFP+ (FortiLink slots)
-
16 x 1GE SFP
-
8 x 5G / 2.5G RJ45 (multi-gig)
-
Dedicated ports: 1 x 2.5G/GE HA + 1 x 1G MGMT
-
2 x USB-A 3.0, RJ45 Console
-
Included transceivers: 2 x 1G SFP SX
This makes it easy to:
-
uplink to core at 25G,
-
connect multi-gig access (Wi-Fi 6/6E/7 uplinks),
-
keep lots of 1G SFP for mixed campus/DC networks.
Hardware features (what makes it 700G class)
SPU acceleration: NP7 + CP10
-
NP7: hyperscale firewall + fast session setup + VPN/VXLAN acceleration + low latency.
-
CP10: accelerates content/security processing (pattern matching, IPS pre-scan, signature correlation).
Platform hardening
-
TPM
-
Signed Firmware Hardware Switch
-
FortiSentry (hardware module): out-of-band filesystem integrity monitoring (nice differentiator for security-conscious customers)
Availability and power
-
Dual internal AC PSU (non-swappable) for 1+1 redundancy
-
1RU rack, forced airflow (side/front-to-back)
Model difference: FG-700G vs FG-701G
-
FG-700G: No onboard storage
-
FG-701G: 960GB onboard SSD (2 x 480GB)
If you’re positioning for customers who want local logging/reporting buffers, the 701G is the cleaner story.
Physical & power (quick spec)
-
Form factor: 1RU
-
Dimensions: 44.45 x 432 x 342 mm
-
Weight: 3.5 kg
-
Power: 230W avg / 283W max (700G), 240W avg / 295W max (701G)
-
Noise: 59 dBA
View data sheet: FortiGate 700G Series Data Sheet
